Light Sources

 Standard  D65, CWF, A, TL84, U30, UV

 Explain of Illuminants

  D65 :  Average North Sky Daylight (CIE F7)  Color Temperature   6500°K

  CWF :  CoolWhite Fluorescent      (CIE F9)  Color Temperature   4180°K

  A   :  Incandescent Commonly used in home and store (CIE A) Color Temperature  2850°K

  TL84 : Tri-phosphor lamp.Commonly used in Europe  (CIE F11) Color Temperature  4100°K

  U30  : Ultralume lamp   Commonly used in America (CIE F12) Color Temperature   3000°K

  UV   : Ultravioret light BLB

  Optional : D75, D50,TL83

Case Colour

 Internal & Out : MUNSELL N7 Neutral grey(Lusterless)

Case Material

  Steel Plate (Powder paint Coating)

Select Switrch

  Membrane

Outer Sizet

  1000mm(W)  680mm(D)  800mm(H)      39.3"(W)   26.7"(D)   31.5"(H)

Viewing Size

    970mm(W)  660mm(D)  560mm(H)      38.2"(W)   25.9"(D)   22.0"(H)

Electric

  100 ∼120/220 ∼240VAC / 50 ∼60Hz

Weight

  88.2lb(40Kg)

Application

  Paint ,Plastics,Paper,Textile,Ink, Wood, Glass, Furniture, Cosmetics, Coating, Graphic Design

  Fashion, Printing, Pigments, Colorants, Glass Food.
